| Type |
Variable-Displacement Axial Piston Pump |
| Name |
Piston Pump |
| Parts No |
355-1015 3551015 PSVL-42CG |
| Machine Number |
304D CR |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT |
| Packing |
As request or standard packing |
1.Precision Load Matching: The variable-displacement design ensures hydraulic flow/torque align with real-time task demands (e.g., more power for digging, less for idling), cutting fuel consumption by 15–20% compared to fixed-displacement pumps.
2.High Torque for Heavy Lifting: With a maximum output pressure of 40 MPa, it delivers enough hydraulic power to lift 10–15 ton loads (critical for 336D2/340D2’s rated digging capacity).
3.Durability in Harsh Conditions: The cast iron housing resists impact and vibration on job sites, while hardened pistons and Viton® seals withstand contamination and extreme temperatures—extending service life to 8,000–12,000 operating hours.
4.Smooth Operation: The swashplate’s gradual angle adjustment eliminates pressure spikes, ensuring jerk-free boom/arm movement and reducing operator fatigue.
MINI HYD EXCAVATOR 304D CR C.ater.pillar.
- More other pump applied to C A T heavey machine
| 2794699 PUMP GP-GEAR |
| 303.5C, 303.5D, 303.5E, 303C CR, 303E CR, 304C CR, 304D CR, 304E, 305.5D, 305.5E, 305C CR, 305D CR, 305E |
| |
| 2706252 PUMP GP-WATER |
| 303.5C, 303.5D, 303C CR, 304C CR, 304D CR, 305.5D, 305C CR, 305D CR, 904B, 904H |
| |
| 2833163 PUMP GP-ENGINE OIL |
| 303.5C, 304D CR |
| |
| 2803730 PUMP GP-WATER |
| 303.5C, 303.5D, 303C CR, 304C CR, 304D CR, 305.5D, 305C CR, 305D CR |
| |
| 2834111 PUMP AS-FUEL INJECTION |
| 303.5C, 304D CR |
| |
| 3177727 PUMP AS-FUEL INJECTION |
| 303.5C, 304D CR |
| |
| 2833183 PUMP GP-FUEL INJECTION |
| 303.5C, 304D CR |
| |
| 3154528 PUMP GP-FUEL PRIMING |
| 303.5C, 303.5D, 304C CR, 304D CR, 305C CR, 305D CR |
| |
| 3545964 PUMP & MTG GP-MAIN HYDRAULIC |
| 304D CR |
| |
| 1492685 PUMP GP-FUEL PRIMING |
| 30/30, 303.5C, 303.5D, 303C CR, 304C CR, 304D CR, 305.5D, 305.5E, 305C CR, 305D CR, 306E, 307D, 307E, 308D, 308E, 35, 45, 527, 539, 55, 550, 554, 570, 580, 908, 910G, 924F, 928G, 938G, 950G, 962G, AP-... |
| |
| 3036502 PUMP AS |
| 304D CR |
| |
| 3154537 PUMP AS |
| 303.5C, 303.5D, 304C CR, 304D CR, 305C CR, 305D CR |
| |
| 3545964 PUMP & MTG GP-MAIN HYDRAULIC |
| 304D CR |
| |
| 3154528 PUMP GP-FUEL PRIMING |
| 303.5C, 303.5D, 304C CR, 304D CR, 305C CR, 305D CR |
| |
| 2833183 PUMP GP-FUEL INJECTION |
| 303.5C, 304D CR |
| |
| 3177727 PUMP AS-FUEL INJECTION |
| 303.5C, 304D CR |
| |
| 2834111 PUMP AS-FUEL INJECTION |
| 303.5C, 304D CR |
| |
| 2803730 PUMP GP-WATER |
| 303.5C, 303.5D, 303C CR, 304C CR, 304D CR, 305.5D, 305C CR, 305D CR |
| |
| 2667944 PUMP GP-MAIN HYDRAULIC |
| 345C, 345C L, 345C MH, W345C MH |
| |
| 3561881 PUMP GP-FUEL PRM & PRIM FILTER |
| 345C, 345C L, 345C MH, 345D, W345C MH |
| |
| 3324917 PUMP GP-GEAR |
| D8T |
| |
| 3586791 PUMP GP-GEAR |
| 735, 735B, 740, 740B, 770G, 770G OEM |
| |
| 2356830 PUMP & MTG GP-IMPL & STEERING |
| 928HZ, 930G |
| |
| 2716440 PUMP & MTG GP-BRAKE & HYD FAN |
| 930G |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
267-1082 |
[1] |
COUPLING-PUMP |
|
| 2 |
281-8128 |
[1] |
HOUSING-FLYWHEEL |
|
| 3 |
355-1015 Y |
[1] |
PUMP GP-PISTON (MAIN HYDRAULIC) |
|
| 4 |
127-4839 M |
[5] |
BOLT (M10X1.25X25-MM) |
|
| 5 |
128-7747 M |
[4] |
BOLT (M10X1.25X40-MM) |
|
| 6 |
191-7503 M |
[3] |
BOLT (M12X1.75X16-MM) |
|
| 7 |
198-4777 |
[1] |
WASHER-HARD (11X25X10-MM THK) |
|
| 8 |
205-6883 |
[1] |
BOLT (M10X1.25X55-MM) |
|
| 9 |
8T-4121 |
[7] |
WASHER-HARD (11X21X2.5-MM THK) |
|
| 10 |
8T-4184 M |
[2] |
BOLT (M12X1.75X45-MM) |
|
| 11 |
8T-4223 |
[2] |
WASHER-HARD (13.5X25.5X3-MM THK) |
|
| |
M |
|
METRIC PART |
|
| |
Y |
|
SEPARATE ILLUSTRATION |
|
- We could supply the following spare parts
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
